CAD Import VCL

CAD Import VCL is a high-quality multi-functional source code provided component for using in Delphi/C++Builder applications. Support of more than 30 both raster and vector formats is provided, including AutoCAD DWG, DXF, DWF, Hewlett-Packard HPGL, PLT, HGL, CGM, SVG, TIFF, BMP, JPG, GIF etc.

CAD Import VCL:

* supports all known CAD formats (DWG/DXF up to 2009, PLT/HPGL/HPGL-2, CGM, SVG, DWF, PS Adobe)
* provides easy access to the properties of CAD entities (see DWG/DXF Entities table)
* fully compatible with Borland Delphi and C++ Builder from 6 up to 2009 versions
* supports Unicode
* Fast Report VCL and Report Builder compatible

CAD Import VCL features
# Easy way to add GIF, TIFF, BMP, JPEG and other formats.
# CAD extentions: *.dwg; *.dxf; *.plt; *.hgl;*.hg;*.hpg; *.plo;*.hp;*.hp1;*.hp2;*.hpgl; *.hpgl2;*.gl2;*.prn;*.spl;
# Capability to add the following extentions: *.tif;*.tiff;*.fax;*.bw;*.rgb;*.rgba; *.sgi;*.cel;*.pic;*.tga; *.vst;*.icb;*.vda;*.win;*.pcd;*.ppm;*.pgm; *.pbm;*.cut; *.pal;*.rla;*.rpf;*.psd;*.pdd;*.psp; *.png *.rle;*.dib; *.ico;*.emf;*.wmf;*.jpg;*.jpeg;*.gif;*.pcx;* *.tif;*.tiff; *.fax;*.bw;*.rgb;*.rgba; *.sgi;*.cel;*.pic;*.tga;*.vst;*.icb;*.vda; *.win;*.pcd;*.ppm;*.pgm; *.pbm; *.cut;*.pal;*.rla;*.rpf;*.psd;*.pdd;*.psp;*.png;*.bmp.
# The Importer provides access to extensive properties of each CAD entity which is supported by CAD Import VCL.
# Easy drawing with TCanvas, TImage, TOpenPictureDialog and other standard classes.
# Full control of every layer and any element of it.
# Supporting three-dimensional coordinates.
# High speed for reading all formats.
# CAD Import VCL implements quick and exact reading of DXF/DWG/HPGL/SVG/CGM files and manipulating them using TGraphic interface.
# DWG and DXF layouts.
# DWG and DXF ACIS entities;
# DXF Autocad Table;
# DWG and DXF reference images;
# HPGL RTL images;
# DWG and DXF Hatch gradients;
# Fast Report VCL and Report Builder compatible.
