Sheet Lightning Pro

Sheet Lightning is a specialized engineering 2D/3D CAD System for creating and unfolding sheet metal designs for fabrication or manufacture. It handles everything from simple cylinders, cones, rectangular ducts and ovals, to adapters, adapting any of these section types, intersections between any of these types and multi-intersections of any of these types. This enables it to handle breeches, lobster-back or segmented bend and very unusual or complex one-off designs. All pieces can have center line offset and oblique or skewed sections. Simple designs are handled with ease through a second parametric environment that requires only the typing of key dimension values to modify the design. A library of standard designs is included. Furthermore all designs created using the full 3D system can be automatically analyzed and converted to a parametric form, then saved as extensions to the existing library. The software integrates to general CAD systems via seamless DXF transfer, exporting both 2D patterns and 3D models. The product has been proven since the earliest version in the worldwide market place since 1990, offering truly unique design capability.
