PCB Wizard Standard Editions is a demo software by New Wave Concepts Limited and works on Windows 10, Windows 8.1, Windows 8, Windows 7, Windows 2012.
You can download PCB Wizard Standard Editions which is 6.28 MB in size and belongs to the software category Science CAD.
PCB Wizard Standard Editions was released on 2011-01-23 and last updated on our database on 2017-03-01 and is currently at version 3.6.
download button
Thank you for downloading from SoftPaz! Your download should start any moment now. It would be great if you could rate and share:
Rate this software:
Share in your network:
features

PCB Wizard Standard Editions Description

  • Circuit diagram:
  • Circuit diagram design
  • Component library (# of models): 500
  • ANSI and DIN symbols
  • Schematic capture
  • Automatic wiring
  • Nets and virtual connections
  • Interactive component and pin hints
  • Link to Livewire for simulation
  • PCB layout:
  • PCB layout design
  • Automatic PCB routing (# of layers):1
  • Routing of flying wire links
  • Bill of Materials reporting
  • Customizable component library
  • NC-Drill export (Excellon format)
  • Gerber export (274-D / 274-X format)
  • General:
  • Multi-level zoom (25%-1000%)
  • Multiple undo and redo
  • Copy and paste to other software
  • Multiple document support
  • Automatic save
  • Integrated text and drawing tools
