Wolfram SystemModeler is a comprehensive application that allows you to create, edit and analyze circuits and systems in various scientific fields. The program enables you to generate specific designs for mechanics, biology, chemistry electricity or thermal systems. It is specialized in both manual design and creating scripts.

Easy to use system generator

Wolfram SystemModeler is dedicated in particular to engineers and technical designers. However, it can successfully be used by students or any other user, with or without extensive knowledge in the field. The program offers a comprehensive collection of components, connectors, functions and other tools that facilitate the design of the desired circuit.
The application includes various templates and libraries, containing basic models, simulations icons or other units created with the Mathematica utility. Several other example sheets are available, each one specialized in a particular science field. You may thus study electrical circuits, trigonometry function charts, physics theories, mechanisms, liquid dynamics and many more.

Versatile system designer

Thanks to its structure, Wolfram SystemModeler allows you to easily manually design your circuit, but also build it by writing the corresponding functions in code language. The program features a user-friendly interface, split into several sections, in order to facilitate the circuit building.
Thus, the column on the left displays the projects, classes, hierarchies and templates, while the column at the far right is a components browser. The working space can easily be resized, for your convenience and allows you to open several instances at the same time, thanks to the tabbed structure. The console at the bottom of the window displays various parameters, allows you to add values, as well as to view compiled scripts.

Model Center and Simulation Center

Wolfram SystemModeler features two dedicated components: the modelling platform, which allows you to manually build your circuit and the simulation area, for testing the functionality of the systems. The Simulation Center can display the functionality parameters for the selected circuit, via charts and plots. Moreover, it allows you to export data as projects or as .MAT / .CSV files.
NOTE: You need to register for a Wolfram ID, in order to obtain an activation code and evaluate the application.
